| Processor |
| Processor operating modes |
64-bit |
| Processor lithography |
14 nm |
| Processor codename |
Coffee Lake |
| Bus type |
DMI3 |
| Maximum internal memory supported by processor |
64 GB |
| Memory types supported by processor |
DDR4-SDRAM |
| Memory clock speeds supported by processor |
2666 MHz |
| Tjunction |
100 °C |
| Thermal Design Power (TDP) |
65 W |
| Processor series |
Intel Core i7-8700 Desktop Series |
| PCI Express configurations |
1×16,1×8+2×4,2×8 |
| Maximum number of PCI Express lanes |
16 |
| Memory bandwidth supported by processor (max) |
41.6 GB/s |
| ECC supported by processor |
No |
| Processor cache type |
Smart Cache |
| Conflict-Free processor |
Yes |
| Processor cache |
12 MB |
| Processor frequency |
3.2 GHz |
| Processor model |
i7-8700 |
| Number of processors installed |
1 |
| Processor boost frequency |
4.6 GHz |
| System bus rate |
8 GT/s |
| Processor socket |
LGA 1151 (Socket H4) |
| Processor threads |
12 |
| Processor cores |
6 |
| PCI Express slots version |
3.0 |
| Processor family |
8th gen Intel® Core™ i7 |
| Memory |
| Memory layout (slots x size) |
4 x 4 GB |
| Internal memory |
16 GB |
| Maximum internal memory |
64 GB |
| Memory slots |
4x DIMM |
| Internal memory type |
DDR4-SDRAM |
| Memory clock speed |
2666 MHz |
| Memory upgrade note |
Additional memory sold separately |
| Memory channels |
Dual |
| Storage |
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| SSD interface |
PCI Express |
| SSD capacity |
512 GB |
| Number of SSDs installed |
1 |
| Card reader integrated |
Yes |
| Compatible memory cards |
SD |
| Total storage capacity |
512 GB |
| Graphics |
| Discrete graphics adapter |
No |
| On-board graphics adapter dynamic frequency (max) |
1200 MHz |
| On-board graphics adapter base frequency |
350 MHz |
| Maximum on-board graphics adapter memory |
64 GB |
| Number of displays supported (on-board graphics) |
3 |
| On-board graphics adapter OpenGL version |
4.5 |
| On-board graphics adapter DirectX version |
12.0 |
| Number of execution units |
24 |
| On-board graphics adapter ID |
0x3E92 |
| On-board graphics adapter family |
Intel® UHD Graphics |
| On-board graphics adapter 4K support |
Yes |
| On-board graphics adapter |
Yes |
| Discrete graphics adapter model |
Not available |
| On-board graphics adapter model |
Intel® UHD Graphics 630 |
| Graphics adapter Open GL support |
Yes |
| Optical drive |
| Optical drive type |
DVD±RW |
| Optical drives quantity |
1 |
| Network |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Ports & interfaces |
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| USB 2.0 ports quantity |
4 |
| PS/2 ports quantity |
2 |
| Microphone in |
No |
| Line-out |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| DVI port |
No |
| DisplayPorts quantity |
2 |
| PowerShare |
Yes |
| Number of USB ports with PowerShare support |
2 |
| On/off button |
Yes |
| Expansion slots |
| PCI Express slots version |
3.0 |
| Technical details |
| Intel 64 |
Yes |
| Cable lock slot type |
Noble |
| Product type |
Workstation |
| Trusted Platform Module (TPM) |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® Quick Sync Video Technology |
Yes |
| Intel® Identity Protection Technology (Intel® IPT) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Product colour |
Black |
| Chassis type |
SFF |
| Audio system |
High Definition Audio |
| Placement supported |
Horizontal/Vertical |
| Cable lock slot |
Yes |
| Design |
| Cable lock slot type |
Noble |
| Product colour |
Black |
| Chassis type |
SFF |
| Placement supported |
Horizontal/Vertical |
| Cable lock slot |
Yes |
| Performance |
| Embedded options available |
No |
| Audio chip |
Realtek ALC3234 |
| Dell E-Value Code |
N006P3430SFFBTPWER |
| Product type |
Workstation |
| Trusted Platform Module (TPM) |
Yes |
| Audio system |
High Definition Audio |
| Software |
| Operating system language |
Multilingual |
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 10 Pro |
| Processor special features |
| Embedded options available |
No |
| Enhanced Intel SpeedStep Technology |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel® OS Guard |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel TSX-NI |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel Stable Image Platform Program (SIPP) |
Yes |
| Intel® Secure Key |
Yes |
| Intel® InTru™ 3D Technology |
Yes |
| Intel Clear Video Technology |
Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Idle States |
Yes |
| Execute Disable Bit |
Yes |
| Intel Software Guard Extensions (Intel SGX) |
Yes |
| Intel Enhanced Halt State |
Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) |
Yes |
| Thermal solution specification |
PCG 2015C |
| Supported instruction sets |
AVX 2.0,SSE4.1,SSE4.2 |
| Scalability |
1S |
| Processor package size |
37.5 x 37.5 mm |
| Processor code |
SR3QS |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| CPU configuration (max) |
1 |
| Intel Virtualization Technology (VT-x) |
Yes |
| Conflict-Free processor |
Yes |
| Processor ARK ID |
126686 |
| Intel 64 |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® Quick Sync Video Technology |
Yes |
| Intel® Identity Protection Technology (Intel® IPT) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Power |
| Power supply input frequency |
50 – 60 Hz |
| Power supply input voltage |
100 – 240 V |
| Certificates |
| Energy Star certified |
Yes |
| Weight & dimensions |
| Width |
92.6 mm |
| Depth |
292 mm |
| Height |
290 mm |
| Weight |
5.12 kg |
| Packaging content |
| AC adapter included |
Yes |
| Manual |
Yes |
| Display included |
No |
| Power cord included |
Yes |
| Mouse included on selected markets only |
Yes |
| Keyboard included on selected markets only |
Yes |
| Other features |
| Trusted Platform Module (TPM) |
Yes |
| On-board graphics adapter |
Yes |
