FortiGate 94D-POE Series

In stock

Overview:

The FortiGate 94D-POE and 98D-POE are high port density, all-in-one security appliances that deliver Fortinets Connected UTM. Ideal for remote, customer premise equipment (CPE) and retail networks, these FortiGates offer the network security, connectivity, and performance you need at a single low per-device price.

Advanced Protection and Wireless Connectivity

You get advanced threat protection, including firewall, application control, advanced threat protection, IPS, VPN, and web filtering, all from one device thats easy to deploy and manage. With its comprehensive management console, remote provisioning and wide range of connectivity options you have an easy-to-deploy, easy-to-manage solution thats great for a centrally managed infrastructure.

Youll appreciate features like WAN Optimization, Data Archiving and VDOMs for your distributed networks. VDOMs on the FortiGate let you segment networks to enable guest and employee access, or protect things like cardholder data to meet compliance standards like PCI and HIPAA.

Built on the foundation of the FortiASIC System on a Chip 2 (SoC2) and FortiOS 5, the FortiGate provides an integrated set of essential security technologies to protect all of your applications and data. You get the industrys best firewall plus the latest in Advanced Threat Protection, Intrusion Protection, Web-filtering and many new features like Sandboxing, Feature Select Options for simplifying configurations and deployments, and Contextual Visibility for enhanced reporting and management.

Features & Benefits

  • 3.5 Gbps throughput performance delivers fast network response
  • Integrated switch and PoE simplify your network infrastructure
  • Multiple PoE interfaces to support IP phones, access points or cameras
  • Runs on FortiOS 5 the most powerful security operating system in the world delivers more security to fight advanced threats, more control to secure mobile devices, and more intelligence to build secure policies
Compare

Get the FortiGate 94D-POE Series at the best price in Uganda from Wodex.NET

Specifications:

FortiGate Model FortiGate 94D-POE FortiGate 98D-POE
Hardware Specifications
GE RJ45 WAN Ports 2 2
GE RJ45 Switch Ports 24 72
FE RJ45 PoE Ports 24 24
GE SFP DMZ Slots 2 4
Included Transceivers 0 0
USB Ports (Client / Server) 1 / 1 1 / 1
Console (RJ45) 1 1
Internal Storage 32 GB 32 GB
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets) 3.5 / 3.5 / 3.5 Gbps
Firewall Latency (64 byte UDP packets) 4 s
Firewall Throughput (Packets Per Second) 5.3 Mpps
Concurrent Sessions (TCP) 2 Million
New Sessions/Second (TCP) 4,000
Firewall Policies 5,000
IPsec VPN Throughput (512 byte packets) 1 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 200
Client-to-Gateway IPsec VPN Tunnels 1,000
SSL-VPN Throughput 35 Mbps
Concurrent SSL-VPN Users (Recommended Maximum) 200
IPS Throughput (HTTP / Enterprise Mix) 275 / 41 Mbps
SSL Inspection Throughput 35 Mbps
Application Control Throughput 34 Mbps
NGFW Throughput 25 Mbps
Threat Protection Throughput 22.5 Mbps
CAPWAP Throughput 260 Mbps
Virtual Domains (Default / Maximum) 10 / 10
Maximum Number of FortiAPs (Total / Tunnel Mode) 32 / 16
Maximum Number of FortiTokens 100
Maximum Number of Registered FortiClients 200
High Availability Configurations Active / Active, Active / Passive, Clustering
Dimensions
Height x Width x Length (inches) 1.72 x 17 x 10.51 3.48 x 11.56 x 17.20
Height x Width x Length (mm) 44 x 432 x 277 88.5 x 293.6 x 437
Form Factor 1 RU 2 RU
Weight 10.6 lbs (4.8 kg) 14.8 lbs (6.7 kg)
Environment
Power Required 110240V AC,
5060 Hz
110240V AC,
5060 Hz
Maximum Current 110 V / 5.4 A,
220 V / 2.9 A
110 V / 6 A,
220 V / 3 A
Total Available PoE Power Budget* 200 W 200 W
Power Consumption (Average / Maximum) 156 / 256 W 163 / 278W
Heat Dissipation 874 BTU/h 949 BUT/h
Operating Temperature 32104F (040C)
Storage Temperature -31158F (-3570C)
Humidity 2090% non-condensing
Operating Altitude Up to 7,400 ft (2,250 m)
Compliance
FCC Part 15 Class B/A, C-Tick, VCCI, CE, UL/cUL, CB
Certifications
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN

Hardware:

FortiGate 94D-POE

Interfaces

  1. USB Management Port
  2. 2x GE RJ45 WAN Ports
  3. 24x GE RJ45 Switch Ports
  4. 24x FE RJ45 PoE Ports
  5. 2x GE SFP DMZ Slots
  6. Console Port
  7. USB Port

Powered by SPU SoC2

  • Combines a RISC-based CPU with Fortinets proprietary SPU content andnetwork processors for unmatched performance
  • Simplifies appliance design and enables breakthrough performance for smaller networks
  • Supports firewall acceleration across all packet sizes for maximum throughput
  • Delivers accelerated UTM content processing for superior performance and protection
  • Accelerates VPN performance for high speed, secure remote access

Install in Minutes with FortiExplorer

The FortiExplorer wizard enables you to easily and quickly set up and configure FortiGate and FortiWiFi platforms with easy-to-follow instructions. The application runs on Windows, Mac OS X desktops and laptops as well as popular mobile devices. Simply connect to the appropriate USB port on the appliance, and be fully protected in minutes.

3G/4G WAN Connectivity

The FortiGate/FortiWiFi 90D Series includes a USB port that allows you to plug in a compatible third-party 3G/4G USB modem, providing additional WAN connectivity or a redundant link for maximum reliability.
